PRINCIPLE PARTICULARS
Length Overall : 44.80m
Length WL : 43.60m
Length BP : 42.00m
Beam Moulded : 10.20m
Depth Moulded : 4.22m
Draft Design : 3.25m
Gross Tonnage : 493
Net Tonnage : 209
Speed : 10.3knots
Class Notation : BV
TANKAGE
Fuel Oil : 950 m3 (Approx.)
Fresh Water : Tons (Approx.)
Ballast Water : Tons (Approx.)
MACHINERIES / PROPULSION
Main Engines : 2 x 373 KW@1800rpm CUMMINS KT19
Gearbox : R/R 6.5 : 1 MASSON MARINE
Main Generators : Cummins 2 x 80 KW 1500 RPM 415/220V
Boom Crane (Telescopic) : 0.9 mton @ 10m
AUXLIARY EQUIPMENTS
F.O. Pump : ITUR RC1
Bilge & Ballast Pump : DESMI/KCB GMP B3ZPM-A
Oily Water Separator : BRANSTORM (BOSS 0.5T/107)
Air-Conditioning : MARINE HVAC PACKAGE
ACCOMMODATION
2 x 1 man Cabin : 2 men
3 x 2 man Cabin : 6 men
Total : 8 men
DECK MACHINERIES
Anchors : 2 x 900kg
Anchor Chain : 247.5m x 18mm
Anchor Windlass : 28mm Electro Hydraulic
NAVIGATION & COMMUNICATION EQUIPMENTS
Radar : 1715 MKII [24NM]
GPS : GP-32
Echo Sounder : FURUNO FE700
Compass : DAIKO
VHF : ICOM IC-M304
SSB RADIO : IC-M710
EPIRB : MC MURDO E5
SAFETY APPLIANCES
Life Rafts : 2 x 15 people
Lifebuoy : 8 PCS
Lifejacket : 8 PCS
Fire Alarm System : CO2 SYSTEM
BOW THRUSTER
Model : 30TT125. 30 inch Tunnel 125hp hydraulic
thruster by Thrustmaster, Texas
PUMPS
Main Cargo Pump : 2 UNITS
Type : DOUBLE SCREW
Manufacturer : SANKO / RUSH PUMPEN / HG
Model : HG 2W7-112
Flow Capacity (CM) : 350M3/HR
Available Power (KW/RPM) : 165/1800
Maximum Pressure : 0.6
BALLAST HANDLING PUMP (PORT)
Type : Self Priming Centrifugal Pump
Manufacturer : DESMI/KCB Or Equal
Flow Capacity (CPH) : 95M3/Hr
Available Power : 17.5KW / 2950RPM |
|
